Bundle Turner; "Hulk"

The "Hulk" series Packman has been introduced to accomodate customers with product mass capacities beyond 8,000lbs and or 50" in bunk height. Used for inverting MDF bunks, steel sheets/blanks, and or forgings. It operates on a 75-90 second cycle time and is controlled with a tethered remote panel 20-foot whip. Custom arm attachments accommodate a variety of standard products, and the system offers a maximum opening of up to 79 inches. Designed for efficiency, it inverts materials in a fluid two axis motion.

Bundle Turner; "Hulk"

    • 15,000lb Load Capacity
    • Opening
      • Min- 10"/24"
      • Max- 60"/79"
    • All Electric Operation
    • PLC Controlled with 7" HMI Operator Interface
    • Mechanically Adjustable Clamping Pressure
    • Ball Screw Actuated Clamping Arms
    • On site assembly required
    • 208/230/240 Volts
      • 3 Phase
      • 60 HZ
      • 50 Amps
    • 440/460/480 Volts
      • 3 Phase
      • 60 HZ
      • 30 Amps
